Direct drives allow highly dynamic and continuous movement and with this, a constant flow of new machining concepts. Peiseler took the lead in this technology as early as 1997 with the development of the world"s first subdevice with a direct drive, just as it did with the first two-axis rotary tilt table with a direct drive in 2001. Today, we are in the technologically leading position to offer you direct drives for turning operations in S1 continuous milling. Increasing machine speed while maintaining bearing rigidity at a level that is also suitable for milling enables us to combine turning and milling applications. This allows Peiseler"s development engineers to use machining centres more flexibly. Direct drives use very sensitive control technology and place high demands on energy supply.

Direct drives allow highly dynamic and continuous movement and with this, a constant flow of new machining concepts. Peiseler took the lead in this technology as early as 1997 with the development of the world"s first subdevice with a direct drive, just as it did with the first two-axis rotary tilt table with a direct drive in 2001. Today, we are in the technologically leading position to offer you direct drives for turning operations in S1 continuous milling. Increasing machine speed while maintaining bearing rigidity at a level that is also suitable for milling enables us to combine turning and milling applications. This allows Peiseler"s development engineers to use machining centres more flexibly. Direct drives use very sensitive control technology and place high demands on energy supply.

Precision machining specialists Peiseler have integrated WITTENSTEIN’s Galaxie® G215 hollow-shaft gearbox into the drive system of their new ZASG 400 two-axis rotary tilt table. The result is a rotary tilt unit combining a compact design with high economic efficiency that positions workpieces fast and extremely accurately ready for machining.

Changing, tilting, turning and rotating – around 170 people at Peiseler’s two factories in Remscheid and Morbach (Germany) manufacture dividing heads and rotary tilt tables in leading-edge technology to enable highly precise and dynamic positioning of workpieces in machine tools. These solutions are ideal wherever space is limited; depending on the model, workpieces weighing anything from a few grams to 50 tons can be moved and held absolutely precisely. The company can look back on more than two centuries of experience in the engineering industry – over 55,000 Peiseler-made dividing heads and rotary tilt tables are currently in action worldwide.

Reversible clamp, 4th axis, rotary table, rotary dividing table, controlled rotary table, dividing attachment, dividing head, rotary indexing table rotary coupling

Indexing table 380 mm diameterDiameter graduation directly in 15 degree steps24 he graduation via index boltdirectly with crank and index plate7 Clamping fluteswidth 12 mmGes. height 120 mmWeight 55 kg

Compact precision small rotary table, suitable for single part or small series production in laser welding precision mechanics. A horizontal or vertical assembly is possible.

It is particularly suitable as a 4th axis on engraving and milling machines for engraving, lasering, drilling, grooving, slot milling, or for use on a tool or surface grinding machine.

6.-Round plate Ø 400mm fixed to the table´s saddle through a precision and combined THK type bearing, type RE25025 and a radial rigid one at the back. This offers a great rigidity t...

Together with our customers, we realize individual, high-quality rotary tables, reversible clamps, two-axis swivel devices, spindle heads and workpiece changing systems for rotary positioning tasks in machine tool construction.

Regardless of whether you perform 5-axis milling, simultaneous machining or turn-milling operations, with the ZASD series with high-torque direct drives, Peiseler offers the ideal solution for every need and every application.

A very high quality unused CNC rotary table manufactured by Peiseler of Germany. For use in the vertical position (horizontal axis) fitted with a pneumatic brake system and is offered in the first instance without motor or encoder, but could be prepared for any machine tool integration. General specifications:Centre height120mmOverall height190mmThrough hole35mmSpindle diameter120mmCarrying capacity36kgMotor mounted to the left hand side, you should check for limitations in the Y axis traverse to ensure that there is no collision with the rear of the machine covers or the doors of the machine.

A rotary table is a precision work positioning device used in metalworking. It enables the operator to drill or cut work at exact intervals around a fixed (usually horizontal or vertical) axis. Some rotary tables allow the use of index plates for indexing operations, and some can also be fitted with dividing plates that enable regular work positioning at divisions for which indexing plates are not available. A rotary fixture used in this fashion is more appropriately called a dividing head (indexing head).

The table shown is a manually operated type. Powered tables under the control of CNC machines are now available, and provide a fourth axis to CNC milling machines. Rotary tables are made with a solid base, which has provision for clamping onto another table or fixture. The actual table is a precision-machined disc to which the work piece is clamped (T slots are generally provided for this purpose). This disc can rotate freely, for indexing, or under the control of a worm (handwheel), with the worm wheel portion being made part of the actual table. High precision tables are driven by backlash compensating duplex worms.

The ratio between worm and table is generally 40:1, 72:1 or 90:1 but may be any ratio that can be easily divided exactly into 360°. This is for ease of use when indexing plates are available. A graduated dial and, often, a vernier scale enable the operator to position the table, and thus the work affixed to it with great accuracy.

Rotary tables are most commonly mounted "flat", with the table rotating around a vertical axis, in the same plane as the cutter of a vertical milling machine. An alternate setup is to mount the rotary table on its end (or mount it "flat" on a 90° angle plate), so that it rotates about a horizontal axis. In this configuration a tailstock can also be used, thus holding the workpiece "between centers."

With the table mounted on a secondary table, the workpiece is accurately centered on the rotary table"s axis, which in turn is centered on the cutting tool"s axis. All three axes are thus coaxial. From this point, the secondary table can be offset in either the X or Y direction to set the cutter the desired distance from the workpiece"s center. This allows concentric machining operations on the workpiece. Placing the workpiece eccentrically a set distance from the center permits more complex curves to be cut. As with other setups on a vertical mill, the milling operation can be either drilling a series of concentric, and possibly equidistant holes, or face or end milling either circular or semicircular shapes and contours.

with the addition of a compound table on top of the rotary table, the user can move the center of rotation to anywhere on the part being cut. This enables an arc to be cut at any place on the part.

Additionally, if converted to stepper motor operation, with a CNC milling machine and a tailstock, a rotary table allows many parts to be made on a mill that otherwise would require a lathe.

Rotary tables have many applications, including being used in the manufacture and inspection process of important elements in aerospace, automation and scientific industries. The use of rotary tables stretches as far as the film and animation industry, being used to obtain accuracy and precision in filming and photography.

Brown and Holmes are the exclusive UK and Ireland agents/distributors for Peiseler indexers, trunnions and special pallet systems. We also support existing and future owners of these Peiseler products with afull service and repair service, using genuine manufacturer parts.

Founded in 1819, the reliability and reputation of Peiseler products is second to none and a key reason for Brown and Holmes to offer them to its customers.

Peiseler rotary tables are available as single-axis and multi-axis with faceplates ranging from 80 to 3,500 mm diameter, with net weight holding capabilities up to 22,000 kg.

Clamping with axial-movement effects zero torsion on the faceplate, Peiseler install greased clamping discs and a material combination to prevent contact corrosion during lifetime

For the rotary manifolds we use a combination of hardened steel and nonferrous material for long lifetime, the seals were developed with a manufacturer especially for Peiseler to achieve long lasting function

We bring a lot of flexibility to adapt different systems like rotary manifold, zero point clamping systems, chucks, HSK System or any other clamping system to our units
