stainless steel pressure safety valve free sample

For corrosion resistance in wet conditions and harsh environments, these valves have a 303 stainless steel body. They spring fully open at the set pressure and remain open until the system pressure is restored below the set pressure. All meet ASME Code Section VIII for use with air and inert gas pressure vessels. Valves have a vented relief port to exhaust discharge directly.

With a 316 stainless steel body for exceptional corrosion resistance, these valves are often used in wet conditions and harsh environments. They spring fully open at the set pressure and remain open until the system pressure is restored below the set pressure. All meet ASME Code Section VIII for use with air and inert gas pressure vessels. Attach a drain line to the threaded relief port for remote discharge.

To Order: Please specify medium (air or inert gas) and set pressure in 1 psi increments (from 150 to 2,700 psi for valves with 1/2 or 1 inlet pipe size, or 150 to 2,269 psi for valves with 3/4 inlet pipe size).

Design a valve specifically for your process media and set pressure. Choose from a valve for air, inert gas, water, hydraulic oil, fuel oil, gasoline, or diesel fuel and a set pressure from 150 to 3,300 psi. These valves begin opening at the set pressure and fully open at about 10% over the set pressure. They begin closing as pressure drops and fully close when the system pressure is restored below the set pressure. Body is 316 stainless steel for exceptional corrosion resistance.

Withstand more than six times the inlet pressure of standard pressure-regulating valves. These valves automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range. Valves have a 303 stainless steel body for corrosion resistance in harsh environments.

Often used in wet conditions and harsh environments, these valves have a 316 stainless steel body for excellent corrosion resistance. They automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range.

To maintain contaminant-free standards in clean room environments, these valves come cleaned and bagged to Fed. Std. Class 100 and ISO Class 5 clean room standards and have a 316 stainless steel body with a smooth finish to resist dust collection. They automatically reduce a high, variable inlet pressure to a lower, stable output pressure. Adjust the outlet pressure within the range. Valves are no-bleed style, so they keep process media contained within the valve.

Often used on dispensers, humidifiers, and fountains, these valves have a 316 stainless steel body that can stand up to deionized water and corrosive conditions. They automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range. Valves have a low-profile body to fit in tight spots. All have a gauge port.

Change outlet pressure without using a gauge—turn the dial to adjust the outlet pressure in 5 or 10 psi increments. These valves automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. They also have an internal strainer to trap debris. Union fittings on both ends of the valves disassemble for easy valve installation and removal. All of these valves meet Canadian safety standards for pressure-reducing valves. Some also meet American and international plumbing safety and performance standards.

To regulate inlet pressures up to 6,000 psi in wet conditions and harsh environments, these valves have a 316 stainless steel body for exceptional corrosion resistance. They automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range. Valves have threads below the adjustment knob and come with a panel-mount nut. All have two gauge ports. They are no-bleed style, so they keep the process gases contained in the valve.

Commonly used for oxygen service and other high-purity applications, these valves come cleaned and bagged to prevent contamination. All automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range. Valves have threads below the adjustment knob and come with a panel-mount nut. They can also be surface mounted. All have two gauge ports. Body is 316 stainless steel for exceptional corrosion resistance. Valves are no-bleed style, so they keep process gases contained in the valve.

Maintain contaminant-free standards in clean room environments. These valves come cleaned and bagged to Fed. Spec. Class 100 and ISO Class 5 clean room standards and have a 316 stainless steel body with a smooth finish to resist dust collection. They automatically reduce a high, variable inlet pressure to a lower, stable output pressure. Valves have threads below the adjustment knob and come with a panel-mount nut. Adjust the outlet pressure within the range.

Regulate steam pressure in wet environments and harsh conditions with these valves that have a 316 stainless steel body for exceptional corrosion resistance. They automatically reduce a high, variable inlet pressure to a lower, stable outlet pressure. Adjust the outlet pressure within the range.

Regulate air, gas, and liquid pressure on food, beverage, and pharmaceutical lines with these valves—they’re 3-A certified to meet sanitary design standards. Attach them to your line to reduce a high, variable inlet pressure to a lower, stable outlet pressure.

Twist the T-handle on top of the valve to adjust the outlet pressure. When the valve is closed, a seal on the outlet prevents leaks and helps maintain consistent pressure. These valves meet ANSI/FCI 70-2 Class III, which means a maximum of 0.1% of fluid, gas, or air can escape while they are fully closed. The spring and valve mechanism are sealed behind the diaphragm, so contaminants can’t enter. Both the diaphragm and seals hold up to water, detergents, and chemicals. They’re also FDA compliant for direct contact with food.

Made of 316 stainless steel, these valves won’t corrode from frequent washdowns with harsh cleaners. They connect to your line with quick-clamp sanitary fittings, also known as tri-clamp connections, which are easier to remove and sanitize than threaded connections. The polished interior is extremely smooth, so there’s nowhere for bacteria to hide. They’re also self-draining, so liquids drain completely and don’t contaminate your line. Keep these valves open during clean-in-place (CIP) cycles with a locking pin.

Designed to reduce contaminants in high-purity applications using hydrogen and methane gas, these valves have a stainless steel and brass body with a smooth finish to reduce dust collection and internal components designed to protect the seal and diaphragm from contamination. They’re often used in research sample systems, emission monitoring systems, and chromatography. Valves automatically reduce a high inlet pressure from compressed gas tanks to a lower, stable outlet pressure. All have Compressed Gas Association (CGA) numbered inlet fittings for secure connections to compressed gas tanks. Choose a valve with the same CGA number as your tank and other system components. Outlet fittings are Swagelok® for a leak-free seal around hard metal tubing in high-pressure lines. Also known as instrumentation fittings, Swagelok® fittings are compatible with Parker A-Lok, Gyrolok, Bilok, and Tylok fittings. Valves come with a gauge to monitor outlet pressure and a gauge to monitor inlet pressure from the tank.

Choose a valve with a maximum outlet pressure that’s approximately twice your application’s normal operating pressure. Your operating pressure should never exceed 75% of the valve’s maximum outlet pressure.

Single-stage valves reduce pressure in one step, which causes the outlet pressure to fluctuate slightly as you empty the tank. They’re best for applications where a constant outlet pressure isn’t critical.

Two-stage valves progressively reduce pressure over two steps for more consistent outlet pressure at all times. They’re often used in applications that require a constant outlet pressure regardless of the tank level.

Designed to meet 3-A sanitary standards, these valves regulate liquid, gas, and air pressure in hygienic zones of food and beverage plants. They’re often used at the end of pipelines on processing and sanitizing equipment. Made of 316 stainless steel, they won"t corrode from frequent washdowns with harsh cleaners. With an extremely smooth interior that self-drains, bacteria won"t have time or space to grow. The spring and internal valve mechanisms are sealed off behind the diaphragm, which also prevents contamination. They connect with quick-clamp fittings, so disassembling to clean your line takes little time.

These valves obstruct flow to maintain sufficient operating pressure in your system. If the system pressure exceeds the set pressure, they exhaust through the outlet. They meet ANSI/FCI 70-2 Class III standards for shut-off valves, meaning a maximum of 0.1% of fluid, gas, or air will escape through the outlet when they’re closed. An integrated T-handle lets you set the outlet pressure without additional tools. The diaphragm and seal resist repeated exposure to water, and they’re FDA compliant for direct contact with food.

To set the pressure, unscrew the cap and turn the adjustment screw. Valves begin opening at the set pressure and fully open at about 10% over the set pressure. They begin closing as pressure drops and fully close when the system pressure is restored below the set pressure.

An external nut lets you adjust the pressure without disassembling the valve. These valves begin opening at the set pressure and fully open at about 10% over the set pressure. They begin closing as pressure drops and fully close when the system pressure is restored below the set pressure.

Recommended for all cold water system installations - to protect against damage to piping and pressure tanks. PRV"s are set at 75 PSI or 100 PSI. PRV"s have a plus/minus 15% setting accuracy

Note: Merrill pressure relief valves may not reseat themselves after pressure relief. Manual disassembly and reseating of the valve may be required. Repeated opening of a pressure relief valve is beyond intended use and voids warranty

*Note: ALL PRV valves are field adjustable - by removing the cap and turning internal disk down to increase pressure. Field adjustment of valve voids warranty.

Warning: ALL PRV, SSPRV, and PRVNL valves must be set a minimum of 15 PSI above the typical high of the water system pressure, so valve chatter or rapid open and close will not occur. Valve chatter can cause the failure of the valve and voids warranty.

Relief Valves└ Valves & Manifolds└ Hydraulics, Pneumatics, Pumps & Plumbing└ Business & IndustrialAll CategoriesAntiquesArtBabyBooks & MagazinesBusiness & IndustrialCameras & PhotoCell Phones & AccessoriesClothing, Shoes & AccessoriesCoins & Paper MoneyCollectiblesComputers/Tablets & NetworkingConsumer ElectronicsCraftsDolls & BearsMovies & TVEntertainment MemorabiliaGift Cards & CouponsHealth & BeautyHome & GardenJewelry & WatchesMusicMusical Instruments & GearPet SuppliesPottery & GlassReal EstateSpecialty ServicesSporting GoodsSports Mem, Cards & Fan ShopStampsTickets & ExperiencesToys & HobbiesTravelVideo Games & ConsolesEverything Else

Stainless Steel Safety Relief Valve is a safety mechanism deployed in applications to prevent them from bursting under pressure. Suraj Metal Corporationis a leading manufacturer and supplier of the different types such as the Brass Safety Valveand others in various sizes and dimensions. The valves are fitted with the pipelines in a way that when the pressure goes above the threshold level, the Stainless Steel Air Safety Valveopens up and relieves the system of pressure.

This is important to prevent the pipes from being damaged or bursting under high pressure. The Stainless Steel Safety Exhaust Ball Valveis used in the exhaust systems where the temperature plays major role. When the temperature exceeds certain point, it increases pressure and the safety valve opens and balances the pressure in the system. The spring loaded boiler safety valveis used in boilers and heat exchanger systems where steam and hot water are circulated through pipes. There are different gas safety valvetypes and each of these differ in their purpose and functions. Please feel free to contact us for more information on the different types of air compressor pressure relief valveand others with pricing.

We Keep Bulk Stock of CF8 stainless steel Pressure Safety Valve at our stockyard, contact us for Free Sample & stock list, View Brass Safety Valve Dimension chart

find Stainless Steel Safety Exhaust Ball Valve Dimensions, price list, size chart here, Buy ASTM A351 CF8M 316 temperature safety valve at best price in India

Use a sample valve to extract product from your vessel for testing or tasting. We also carry perlick type sample valves that are necessary for use with many Zahm and Nagle CO2 volume testers.

The primary purpose of a pressure relief valve is to protect life, property and the environment. Pressure relief valves are designed to open and release excess pressure from vessels or equipment and then close again.

The function of pressure relief valves differs depending on the main type or loading principle of the valve. The main types of pressure relief valves are spring-loaded, weight-loaded and controlled pressure relief valves.

Regardless of the type or load, pressure relief valves are set to a specific set pressure at which the medium is discharged in a controlled manner, thus preventing overpressure of the equipment. In dependence of several parameters such as the contained medium, the set pressure is individual for each safety application.

The primary purpose of a safety valve is to protect life, property and the environment. Safety valves are designed to open and release excess pressure from vessels or equipment and then close again.

The function of safety valves differs depending on the load or main type of the valve. The main types of safety valves are spring-loaded, weight-loaded and controlled safety valves.

Regardless of the type or load, safety valves are set to a specific set pressure at which the medium is discharged in a controlled manner, thus preventing overpressure of the equipment. In dependence of several parameters such as the contained medium, the set pressure is individual for each safety application.

RL3 Series Externally Adjustable Relief Valves Maintenance Instructions; RL3 Series Externally Adjustable Relief Valves Manual Override Handle Conversion Instructions

Valve sizing often is described by the nominal size of the end connections, but a more important measure is the flow that the valve can provide. And determining flow through a valve can be simple.

Valves for industrial applicationsIn order to prevent the uncontrolled rise in pressure in pressure vessels or pressurized pipelines, a safety valve is inserted. The safety valve is designed so that it opens at a given maximum pressure, thereby relieving the line or the container. Safety valves find their use in almost all areas of the pressure vessel and pipeline construction. In cryogenics as a spring-loaded safety valve for example.

Safety valves and pressure relief valves are crucial for one main reason: safety. This means safety for the plant and equipment as well as safety for plant personnel and the surrounding environment.

Safety valves and pressure relief valves protect vessels, piping systems, and equipment from overpressure, which, if unchecked, can not only damage a system but potentially cause an explosion. Because these valves play such an important role, it’s absolutely essential that the right valve is used every time.

The valve size must correspond to the size of the inlet and discharge piping. The National Board specifies that the both the inlet piping and the discharge piping connected to the valve must be at least as large as the inlet/discharge opening on the valve itself.

The connection types are also important. For example, is the connection male or female? Flanged? All of these factors help determine which valve to use.

The set pressure of the valve must not exceed the maximum allowable working pressure (MAWP) of the boiler or other vessel. What this means is that the valve must open at or below the MAWP of the equipment. In turn, the MAWP of the equipment should be at least 10% greater than the highest expected operating pressure under normal circumstances.

Temperature affects the volume and viscosity of the gas or liquid flowing through the system. Temperature also helps determine the ideal material of construction for the valve. For example, steel valves can handle higher operating temperatures than valves made of either bronze or iron. Both the operating and the relieving temperature must be taken into account.

Back pressure, which may be constant or variable, is pressure on the outlet side of the pressure relief valve as a result of the pressure in the discharge system. It can affect the set pressure of the upstream valve and cause it to pop open repeatedly, which can damage the valve.

For installations with variable back pressure, valves should be selected so that the back pressure doesn’t exceed 10% of the valve set pressure. For installations with high levels of constant back pressure, a bellows-sealed valve or pilot-operated valve may be required.

Different types of service (steam, air, gas, etc.) require different valves. In addition, the valve material of construction needs to be appropriate for the service. For example, valves made of stainless steel are preferable for corrosive media.

Safety valves and relief valves must be able to relieve pressure at a certain capacity. The required capacity is determined by several factors including the geometry of the valve, the temperature of the media, and the relief discharge area.

These are just the basic factors that must be considered when selecting and sizing safety valves and relief valves. You must also consider the physical dimensions of the equipment and the plant, as well as other factors related to the environment in which the valve will operate.

WITT is a manufacturer of Pressure relief valvesor Safety relief valves for technical gases. They are designed to protect against overpressure by discharging pressurized gases and vapors from pipelines, pressure vessels and plant components. Safety relief valves (SRV) are often the last line of defense against explosion – and such an explosion could be fatal. Other common names for safety relief valves are pressure relief valve (PRV), safety valve, pressure safety valve, overpressure valve, relief valve or blow-off valve.

WITT safety valves are very precise. They are individually preset to open at a predetermined pressure within the range 0.07 to 652 Psi. Their small size and orientation-independent installation allow a wide range of connection options. WITT relief valves also stand out due to their high blow-off flow rates of up to 970m³/h. They can be used within a temperature range of -76° F to +518°F and even with very low pressures.

For maximum safety, WITT undertakes 100 % testing of each safety relief valve before it is delivered. In addition, WITT offers individual testing of eachsafety valveby the TÜV, with their certificate as proof of the correct set pressure.

WITTsafety relief valvesare direct-acting, spring-loaded valves. When the preset opening pressure is reached, a spring-loaded element in the valve gives way and opens, and the pressure is relieved. Once the pressures are equalized, the valve closes automatically and can be reactivated any time the pressure rises again. Depending on the application and the nature of the gas, the safety relief valvescan either discharge to atmosphere, or via a connected blow-off line. The opening pressure of the safety valves is preset by WITT at the factory according to the customer’s requirements.

Safety relief valvesare used in numerous industries and industrial applications where, for example, gases pass through pipelines or where special process vessels have to be filled with gas at a certain pressure.

For most industrial applications using technical gases, brass is usually the standard material of construction of thesafety relief valvebody/housing. For the use of pressure relief valves with aggressive and corrosive gases, the housings are made of high-quality stainless steel (1.4541/AISI 321, 1.4404/AISI 316L, 1.4305/AISI 303 or 1.4571/AISI 316Ti). The use of aluminium as a housing material is also possible.

Depending on the type of gas used and individual customer requirements, various sealing materials and elastomers are available to ensure the safety of your systems under even the most difficult conditions.

WITT pressure relief valves are available with different connections. In addition to the standard versions with the usual internal or external threads, special versions with KF or CF flanges, VCR or UNF threads can also be ordered. Special adapters for connecting the safety relief valve to a blow-off line are also available.
