The Computer-Aided Design ("CAD") files and all associated content posted to this website are created, uploaded, managed and owned by third-party users. Each CAD and any associated text, image or data is in no way sponsored by or affiliated with any company, organization or real-world item, product, or good it may purport to portray.

The Computer-Aided Design ("CAD") files and all associated content posted to this website are created, uploaded, managed and owned by third-party users. Each CAD and any associated text, image or data is in no way sponsored by or affiliated with any company, organization or real-world item, product, or good it may purport to portray.

Hoist Central offers a comprehensive library of CAD drawings (DWG) for a wide range of industry-leading hoists. Download hoist system CAD files for use when building with overhead material handling.

CAD drawings for Columbus McKinnon brands: CM Hoists, Yale Hoists, Budgit Hoists and Coffing Hoists are available for download. Click on the logo below to reveal that brand"s library.

Wire rope consists of several strands of metal wire laid (twisted) into a helix. The term "cable" is often used interchangeably with "wire rope", but narrower senses exist in which "wire rope" refers to diameter larger than 3/8 inch (9.52 mm), whereas sizes smaller than this are designated cable or cords.wrought iron wires were used, but today steel is the main material used for wire ropes.

Historically wire rope evolved from wrought iron chains, which had a record of mechanical failure. While flaws in chain links or solid steel bars can lead to catastrophic failure, flaws in the wires making up a steel cable are less critical as the other wires easily take up the load. Friction between the individual wires and strands, as a consequence of their twist, further compensates for any flaws.

Wire ropes were developed starting with mining hoist applications in the 1830s. Wire ropes are used dynamically for lifting and hoisting in cranes and elevators, and for transmission of mechanical power. Wire rope is also used to transmit force in mechanisms, such as a Bowden cable or the control surfaces of an airplane connected to levers and pedals in the cockpit. Only aircraft cables have WSC (wire strand core). Also, aircraft cables are available in smaller diameters than wire rope. For example, aircraft cables are available in 3/64 in. diameter while most wire ropes begin at a 1/4 in. diameter.suspension bridges or as guy wires to support towers. An aerial tramway relies on wire rope to support and move cargo overhead.

Modern wire rope was invented by the German mining engineer Wilhelm Albert in the years between 1831 and 1834 for use in mining in the Harz Mountains in Clausthal, Lower Saxony, Germany.chains, such as had been used before.

Wilhelm Albert"s first ropes consisted of three strands consisting of four wires each. In 1840, Scotsman Robert Stirling Newall improved the process further.John A. Roebling, starting in 1841 suspension bridge building. Roebling introduced a number of innovations in the design, materials and manufacture of wire rope. Ever with an ear to technology developments in mining and railroading, Josiah White and Erskine Hazard, principal ownersLehigh Coal & Navigation Company (LC&N Co.) — as they had with the first blast furnaces in the Lehigh Valley — built a Wire Rope factory in Mauch Chunk,Pennsylvania in 1848, which provided lift cables for the Ashley Planes project, then the back track planes of the Summit Hill & Mauch Chunk Railroad, improving its attractiveness as a premier tourism destination, and vastly improving the throughput of the coal capacity since return of cars dropped from nearly four hours to less than 20 minutes. The decades were witness to a burgeoning increase in deep shaft mining in both Europe and North America as surface mineral deposits were exhausted and miner had to chase layers along inclined layers. The era was early in railroad development and steam engines having sufficient tractive effort to climb steep slopes were in the future, so incline plane railways were common, and the mining tunnels along inclined shafts between coal layers were just a which came first variant, but where steam engines could not go. This pushed development of cable hoists rapidly in the United States as surface deposits in the Anthracite Coal Region north and south dove deeper every year, and even the rich deposits in the Panther Creek Valley required LC&N Co. to drive their first shafts into lower slopes beginning Lansford and its Schuylkill County twin-town Coaldale.

The German engineering firm of Adolf Bleichert & Co. was founded in 1874 and began to build bicable aerial tramways for mining in the Ruhr Valley. With important patents, and dozens of working systems in Europe, Bleichert dominated the global industry, later licensing its designs and manufacturing techniques to Trenton Iron Works, New Jersey, USA which built systems across America. Adolf Bleichert & Co. went on to build hundreds of aerial tramways around the world: from Alaska to Argentina, Australia and Spitsbergen. The Bleichert company also built hundreds of aerial tramways for both the Imperial German Army and the Wehrmacht.

In the last half of the 19th century, wire rope systems were used as a means of transmitting mechanical powercable cars. Wire rope systems cost one-tenth as much and had lower friction losses than line shafts. Because of these advantages, wire rope systems were used to transmit power for a distance of a few miles or kilometers.

Steel wires for wire ropes are normally made of non-alloy carbon steel with a carbon content of 0.4 to 0.95%. The very high strength of the rope wires enables wire ropes to support large tensile forces and to run over sheaves with relatively small diameters.

In the mostly used parallel lay strands, the lay length of all the wire layers is equal and the wires of any two superimposed layers are parallel, resulting in linear contact. The wire of the outer layer is supported by two wires of the inner layer. These wires are neighbours along the whole length of the strand. Parallel lay strands are made in one operation. The endurance of wire ropes with this kind of strand is always much greater than of those (seldom used) with cross lay strands. Parallel lay strands with two wire layers have the construction Filler, Seale or Warrington.

In principle, spiral ropes are round strands as they have an assembly of layers of wires laid helically over a centre with at least one layer of wires being laid in the opposite direction to that of the outer layer. Spiral ropes can be dimensioned in such a way that they are non-rotating which means that under tension the rope torque is nearly zero.

The open spiral rope consists only of round wires. The half-locked coil rope and the full-locked coil rope always have a centre made of round wires. The locked coil ropes have one or more outer layers of profile wires. They have the advantage that their construction prevents the penetration of dirt and water to a greater extent and it also protects them from loss of lubricant. In addition, they have one further very important advantage as the ends of a broken outer wire cannot leave the rope if it has the proper dimensions.

Stranded ropes are an assembly of several strands laid helically in one or more layers around a core. This core can be one of three types. The first is a fiber core, made up of synthetic material or natural fibers like Sysal. Synthetic fibers are stronger and more uniform but can"t absorb much lubricant. Natural fibers can absorb up to 15% of their weight in lubricant and so protect the inner wires much better from corrosion than synthetic fibers do. Fiber cores are the most flexible and elastic, but have the downside of getting crushed easily. The second type, wire strand core, is made up of one additional strand of wire, and is typically used for suspension. The third type is independent wire rope core (IWRC), which is the most durable in all types of environments.ordinary lay rope if the lay direction of the wires in the outer strands is in the opposite direction to the lay of the outer strands themselves. If both the wires in the outer strands and the outer strands themselves have the same lay direction, the rope is called a lang lay rope (formerly Albert’s lay or Lang’s lay). Regular lay means the individual wires were wrapped around the centers in one direction and the strands were wrapped around the core in the opposite direction.

Multi-strand ropes are all more or less resistant to rotation and have at least two layers of strands laid helically around a centre. The direction of the outer strands is opposite to that of the underlying strand layers. Ropes with three strand layers can be nearly non-rotating. Ropes with two strand layers are mostly only low-rotating.

Stationary ropes, stay ropes (spiral ropes, mostly full-locked) have to carry tensile forces and are therefore mainly loaded by static and fluctuating tensile stresses. Ropes used for suspension are often called cables.

Track ropes (full locked ropes) have to act as rails for the rollers of cabins or other loads in aerial ropeways and cable cranes. In contrast to running ropes, track ropes do not take on the curvature of the rollers. Under the roller force, a so-called free bending radius of the rope occurs. This radius increases (and the bending stresses decrease) with the tensile force and decreases with the roller force.

Wire rope slings (stranded ropes) are used to harness various kinds of goods. These slings are stressed by the tensile forces but first of all by bending stresses when bent over the more or less sharp edges of the goods.

There are technical regulations for the rope drives of cranes, elevators, rope ways and mining installations not exceeding a given tensile force and not falling short of a given diameter ratio D/d of sheave and rope diameters. A general dimensioning method of rope drives (and used besides the technical regulations) calculate the five limits

Donandt force (yielding tensile force for a given bending diameter ratio D/d) - strict limit. The nominal rope tensile force S must be smaller than the Donandt force SD1.

Rope safety factor = minimum breaking force Fmin / nominal rope tensile force S. (ability to resist extreme impact forces) - Fmin/S ≥ 2,5 for simple lifting appliance

Discarding number of wire breaks (detection to need rope replacement) Minimum number of wire breaks on a reference rope length of 30d should be BA30 ≥ 8 for lifting appliance

Optimal rope diameter with the max. rope endurance for a given sheave diameter D and tensile rope force S - For economic reasons the rope diameter should be near to but smaller than the optimal rope diameter d ≤ dopt.

The wire ropes are stressed by fluctuating forces, by wear, by corrosion and in seldom cases by extreme forces. The rope life is finite and the safety is only ensured by inspection for the detection of wire breaks on a reference rope length, of cross-section loss, as well as other failures so that the wire rope can be replaced before a dangerous situation occurs. Installations should be designed to facilitate the inspection of the wire ropes.

Lifting installations for passenger transportation require that a combination of several methods should be used to prevent a car from plunging downwards. Elevators must have redundant bearing ropes and a safety gear. Ropeways and mine hoistings must be permanently supervised by a responsible manager and the rope must be inspected by a magnetic method capable of detecting inner wire breaks.

The end of a wire rope tends to fray readily, and cannot be easily connected to plant and equipment. There are different ways of securing the ends of wire ropes to prevent fraying. The most common and useful type of end fitting for a wire rope is to turn the end back to form a loop. The loose end is then fixed back on the wire rope. Termination efficiencies vary from about 70% for a Flemish eye alone; to nearly 90% for a Flemish eye and splice; to 100% for potted ends and swagings.

When the wire rope is terminated with a loop, there is a risk that it will bend too tightly, especially when the loop is connected to a device that concentrates the load on a relatively small area. A thimble can be installed inside the loop to preserve the natural shape of the loop, and protect the cable from pinching and abrading on the inside of the loop. The use of thimbles in loops is industry best practice. The thimble prevents the load from coming into direct contact with the wires.

A wire rope clamp, also called a clip, is used to fix the loose end of the loop back to the wire rope. It usually consists of a U-shaped bolt, a forged saddle, and two nuts. The two layers of wire rope are placed in the U-bolt. The saddle is then fitted over the ropes on to the bolt (the saddle includes two holes to fit to the u-bolt). The nuts secure the arrangement in place. Three or more clamps are usually used to terminate a wire rope. As many as eight may be needed for a 2 in (50.8 mm) diameter rope.

There is an old adage; be sure not to "saddle a dead horse." This means that when installing clamps, the saddle portion of the clamp assembly is placed on the load-bearing or "live" side, not on the non-load-bearing or "dead" side of the cable. According to the US Navy Manual S9086-UU-STM-010, Chapter 613R3, Wire and Fiber rope and Rigging, "This is to protect the live or stress-bearing end of the rope against crushing and abuse. The flat bearing seat and extended prongs of the body (saddle) are designed to protect the rope and are always placed against the live end."

An eye splice may be used to terminate the loose end of a wire rope when forming a loop. The strands of the end of a wire rope are unwound a certain distance, and plaited back into the wire rope, forming the loop, or an eye, called an eye splice. When this type of rope splice is used specifically on wire rope, it is called a "Molly Hogan", and, by some, a "Dutch" eye instead of a "Flemish" eye.

Swaging is a method of wire rope termination that refers to the installation technique. The purpose of swaging wire rope fittings is to connect two wire rope ends together, or to otherwise terminate one end of wire rope to something else. A mechanical or hydraulic swager is used to compress and deform the fitting, creating a permanent connection. There are many types of swaged fittings. Threaded Studs, Ferrules, Sockets, and Sleeves are a few examples.

A wedge socket termination is useful when the fitting needs to be replaced frequently. For example, if the end of a wire rope is in a high-wear region, the rope may be periodically trimmed, requiring the termination hardware to be removed and reapplied. An example of this is on the ends of the drag ropes on a dragline. The end loop of the wire rope enters a tapered opening in the socket, wrapped around a separate component called the wedge. The arrangement is knocked in place, and load gradually eased onto the rope. As the load increases on the wire rope, the wedge become more secure, gripping the rope tighter.

Poured sockets are used to make a high strength, permanent termination; they are created by inserting the wire rope into the narrow end of a conical cavity which is oriented in-line with the intended direction of strain. The individual wires are splayed out inside the cone or "capel", and the cone is then filled with molten lead-antimony-tin (Pb80Sb15Sn5) solder or "white metal capping",zincpolyester resin compound.

Manufacturer and distributor of drop forged and light duty swivels made from cast malleable iron, steel and stainless steel materials. Eye, eye-eye, jaw-eye and jaw-jaw end style swivels are offered. Available in various lengths and colors. Capable of preventing over twist stress on the cable, wire rope or chain. Serves the transportation, mining, railroad, construction, architectural, fitness, automotive, marine, OEM, military, display, signage, lighting, security and recreation industries.

Manufacturer of standard & custom machine products including drop forged steel swivels, chain swivels, forged steel swivels, stainless steel swivels & wire rope swivels. Types include zinc plated swivels. Available in sizes ranging from 1/4 in. to 3/4 in., working load limits up to 7200 lbs. & weights up to 3.80 lbs. Types include eye swivels & hot galvanized swivels. Types of castings include investment, sand, lost wax & die castings. Markets served include industrial, marine, transportation, cargo & farm.

Manufacturer of swivels including wire rope, eye & eye & chain swivels. Swivels are made from brass, stainless steel & nickel-plated zinc & are available in various sizes. Swivels are suitable for bags, luggage, locking, marine, pet, strap & harness applications.

Manufacturer of wire rope swivels made from drop forged steel with heat treated threaded components. Types of swivels include eye & eye, chain & jaw & eye swivels. Specifications include 1/4 in. to 3/4 in. size & 0.26 ton & 2 ton working load capacity. Made in USA.

ISO 9002 certified manufacturer & distributor of stainless steel swivels for chains & wire ropes. Types of swivels include swivel eye & double pin swivels. Swivel eye available in lengths ranging from 3.156 in. to 4.937 in., top opening ranging from 1.031 in. to 1.625 in. & bottom opening ranging from 0.562 in. to 0.812 in. Double pin swivels available in lengths ranging from 3.156 in. to 4.750 in., top opening ranging from 0.312 in. to 0.406 in. & bottom opening ranging from 0.437 in. to 0.738 in. Swivels are also available with ball bearings.

Distributor of wire rope attachments and fittings including swivels. Available in a variety of materials, sizes, and strength options. Suitable for project or product assembly in commercial and industrial applications. Other products include sockets, spikes, shackles, clevis and end links, hooks, slings and synthetic slings, eyebolts, and turnbuckles. Serves markets ranging from toys and appliances to heavy mission-critical industrial machinery.

Manufacturer of standard and custom wire rope oval eye swivels made from self-colored steel and zinc plated steel. Available for 0.4375 to 1.375 in. rope sizes. Breaking strength ranges from 17,780 to 113,000 lbs. Capabilities include turning, milling, drilling, tapping, metal fabrication, welding and assembly. Serves the maritime, airport, amusement park, sports stadium, construction, architectural, utility, rigging, military and other industries. Made in the USA.

Distributor of swivels made from steel and stainless steel materials. Load bearing and cable pulling swivels are available. Specifications include 6,000 to 25,000 lbs. capacity. Suitable for eliminating winding and tangling of wire rope or cable during pull. Serves the construction, commercial, institutional, government and utility markets.

Manufacturer and distributor of lift attachments including wire rope swivels. Made from forged steel. Types of swivels include eye/eye, jaw/eye and ring/eye type swivels. Available in different size and load rating capacity models.

Distributor of wire rope swivels. Available in various sizes. Various capabilities include testing, inspection, rental, rigging and calibration. Marine and offshore industries served. Stock items available.

Distributor of automation products & information systems, electrical supplies, industrial MRO & safety supplies, wired & wireless networks, motors, drives, lightning products & emergency power supplies. Products include computers, labels, clutches, tools, saws, fuel tanks, wire & cable, capacitors, transformers, sensors, lamps, ballast & measuring devices. Capabilities include generator service & rental, energy management, preventive maintenance, network installation, motor repair, chemical services include castrol care, chemical management, coolant recycling & machine cleaning.

Custom fabricator & stocking distributor of hot dip, galvanized & drop forged eye & eye swivels for chain & wire rope. Specifications of swivels include 1/4 in. to 1 1/2 in. size, 850 lbs. to 45,200 lbs. working load limit & 0.21 lbs. to 33.09 lbs. weight.

ISO 9001:2008 manufacturer and distributor of wire and wire products. Domestic and import stocking distributor of wire, wire cables, wire ropes and hardware made from steel, stainless steel and other metals in various constructions. Diameter ranges from 1/32 in. diameter to 2 in. and more. Custom spooling, private label, and drop shipments.

Manufacturer & distributor of rigging equipment & supplies including domestic & imported wire rope, blocks, tackle, cable, sleeves, wire rope slings, rigging & logging hardware, chain & wire rope slings in stainless & galvanized steel.

Brewer Titchener, Bridon-American, CM, CM, Campbell, Chicago Hardware, Continental Western, Crosby, Esco, Gunnebo Johnson, Johnson, Letellier, MSI, MacWhyte, Miller, Morse Starrett, Muncy, Newco, Ropemaster Skookum, Ulven, WRCA, Weissenfels, Wolf

Distributor of wire rope swivels. Types of swivels include stainless steel eye & eye swivels, drop forged jaw & eye swivels, drop forged eye & eye swivels, stainless steel jaw & jaw swivels & stainless steel jaw & eye swivels.

ISO 9001:2000 certified manufacturer & distributor of swivels including chain swivels, forged steel swivels & wire rope swivels. Swivel hooks range in working load limit from 3/4 tons to 30 tons in carbon & alloy materials. Services include inspection, repair & testing.

Manufacturer of wire rope swivels. Types include roller and angular contact bearing swivels. Angular contact bearing swivels are available in 3-1/8 in. to 40 in. length. Roller bearing swivels are available in 8-1/4 in. to 18-5/8 in. overall length.

Distributor of wire rope swivels. Other products available include hooks, rigging accessories, safety hoist clamps, sling saver fittings, western and marine blocks and pipe, barrier and curbing grabs are available. Meet ASME B30.26 and ASME B20.26 standards.

ISO 9001:2000 certified manufacturer & distributor of swivels including chain swivels, forged steel swivels & wire rope swivels. Swivel hooks range in working load limit from 3/4 tons to 30 tons in carbon & alloy materials. Services include inspection, repair & testing.

Distributor of standard & custom industrial lifting & rigging products & fittings including wire rope swivels. Wire rope swivels are available as jaw end swivels in different sizes with different rated load capacities.

Manufacturer and distributor of swivels. Types of swivels include chain, forged steel, stainless steel & wire rope. Additional products include wire, cable, hoists, hooks, slings & winches.

Distributor of stainless steel wire rope swivels. Available in 3/16 in. to 1/2 in. chain sizes with 750 lbs. to 4,730 lbs. capacity. Various other products available include nails, nuts, manifolds, lugs, mounts, paints, pliers, protectors, clamps and pins. Vendor managed inventory (VMI) programs available. JIT delivery.

If the force F is applied to the pin at other than the specified direction, the theoretical bridge output will be due tithe component of the force along the sensitive direction, i.e. F cos X (please see More Images Box - "Force F Direction"). Therefore, typical pins incorporate an anti-rotation device for proper alignment . (see Clevis Pin Installation Download)

Jakob Rope SystemsJakob Rope Systems is one of the market leaders in the manufacture and supply of top-end, design-forward solutions to industrial and construction-related rope and cable applications in which elegance, simplicity and superlative quality are required.

Now, for more than a century and in over 55 countries, Jakob offers a range of steel rope products to our clients who return time and again seeking a reliable maker and provider of stainless steel wire ropes, rod fasteners, nets and unique fittings, all custom-designed and produced to fit exact specifications. At Jakob, we understand it’s the little details that make the big differences.

Every piece of finished goods leaving our warehouses is put through a stringent testing process to ensure compliance with AISI 316, ISO and DIN standards. Our cable railing, wire mesh, wire ropes, and rods can be used in multiple applications, both indoor and outdoor and at various scales, such as sign stanchions, shelving, as trellises on green walls, safety netting, and even in zoo enclosures.

Jakob and our USA -based team can provide cables and wire netting solutions for any commercial and business application. We take pride in offering custom-made designs to fit our clients’ needs.

The Nemag Quick Release Link has been balanced and perfected to become the most reliable, quickest and safest coupling method for ropes and chains. The contact surface of the C-section has been hardened, which considerably lengthens the life span. The construction of the locking piece ensures reliable functioning; even under severe circumstances. The locking pieces are interchangeable.

Warning: The working load is the recommended maximum load for grabbing operations when Quick Release Links and Rope Pear Sockets are passing over a special cable sheave. For other applications a safety factor in line with official international and national guidelines has to be adhered to.

At Socitec. We provide all-metal, multi-directional Helical wire rope isolators with exceptional endurance and reliability, high adaptability, excellent resistance, and other great features. It comes in standard models of 6, 8, or 10 cable loops, and you can always request a special model.

Socitec took care of everything you need in your anti-vibration helical wire rope isolator to secure protection for your equipment, So, we encourage you to order your isolator Now!
