Hoist Central offers a comprehensive library of CAD drawings (DWG) for a wide range of industry-leading hoists. Download hoist system CAD files for use when building with overhead material handling.

Jakob Rope SystemsJakob Rope Systems is one of the market leaders in the manufacture and supply of top-end, design-forward solutions to industrial and construction-related rope and cable applications in which elegance, simplicity and superlative quality are required.

Now, for more than a century and in over 55 countries, Jakob offers a range of steel rope products to our clients who return time and again seeking a reliable maker and provider of stainless steel wire ropes, rod fasteners, nets and unique fittings, all custom-designed and produced to fit exact specifications. At Jakob, we understand it’s the little details that make the big differences.

Every piece of finished goods leaving our warehouses is put through a stringent testing process to ensure compliance with AISI 316, ISO and DIN standards. Our cable railing, wire mesh, wire ropes, and rods can be used in multiple applications, both indoor and outdoor and at various scales, such as sign stanchions, shelving, as trellises on green walls, safety netting, and even in zoo enclosures.

Jakob and our USA -based team can provide cables and wire netting solutions for any commercial and business application. We take pride in offering custom-made designs to fit our clients’ needs.

Models are available in a range of file formats including .rfa, .ifc, and .dwg and offer full connectivity to product data which can be used to aid cost management, construction collaboration and facilities management. The Technical Services can also provide initial training to ensure the correct placement of Gripple BIM objects in 3D models.

The big brother to Wachs DW Guillotine® 208 diamond wire saw, the DWG 416 is designed for cutting 4 inch to 16 inch (DN100-400) pipe including steel, ductile, cast iron, concrete (CA), poly, PVC and mixed media. The DWG 416 features exceptional build quality, with stainless steel and aluminum construction for corrosion resistance, and a collapsible, folding arm design that allows it to be easily transported and stored.

Like all Wachs cutting solutions, the DWG 416 is secured to the pipe by a quick, secure chain mounting system, eliminating the danger of kickback accidents due to binding from pipe shifting or compression cuts. Hydraulically powered using a sealed loop, the DWG 416 can operate under the most extreme conditions, including full water immersion, and is ideal for cutting in restrictive spaces.

The DWG series diamond wire is long lasting, giving the DWG 416 one of the lowest costs per cut in the industry. Like the smaller DWG 208, it utilizes a fully enclosed, high speed diamond infused cutting wire that rotates radially while cutting, allowing all the diamond elements to come into contact with the workpiece. Apart from the safety advantages, the lower cost of consumables over the life of the machine compared to handheld devices will offset its higher initial cost.

Top mounted controls for wire speed and feed allow the operator to select the optimum settings for a quick, clean cut. Wachs DWG 416 comes complete with a heavy duty carrier for ease of transport and to protect the saw in transit and storage.
