small hydraulic pump units manufacturer

The hydraulic power unit is comprised of several key parts and components. The three main components of a hydraulic power unit are the motor pump, accumulator and reservoir tank. The power unit’s pump is responsible for pulling the working fluid out of the reservoir tank and moving it into the accumulator. The accumulator is a container which collects the hydraulic fluid and helps build and maintain pressure in the system.

Once the pressure within the accumulator has reached a pre-set level, the fluid is released and circulated in the hydraulic system. The fluid moves the components of the motor, which in turn rotates the shaft that supplies mechanical power. The fluid is then discharged into the reservoir, where it will work its way back into the pump and continue the cycle.

In hydraulic cylinders, the hydraulic power unit pumps hydraulic fluid into the bottom chamber of the cylinder and pushes the piston rod up, which pushes the fluid in the other chamber back into the reservoir. The movement of this fluid pressurizes the chamber and extends the piston to its full length, giving the hydraulic cylinder its ability to push. Since these systems can require high pressures, it is important that these power units be equipped with temperature regulation equipment.

Coolers and heaters are used to ensure that the hydraulic fluid remains within operational parameters and to make sure that the hydraulic equipment does not sustain any damage. Power units can be used for a huge range of applications, including in aerospace test equipment, automation equipment, heavy machinery, marine equipment, and machine tools.

Manufacturer of power units including pumps and valves. High pressure waterjet cutting pumps are available in 3.8 L/min maximum capacity, 4,000 bar pressure, 30 kW power, 1 pressure booster and less than 72 dB noise level. Check valves offered in 7,000 to 10,000 bar pressure for metal to metal seating. Air actuated valves are provided in up to 7,000 bar pressure and 160 or 200 mm actuator size. Hydraulic pump has an electronic pressure control and a safety valve that nullifies system pressure when the pump switches off. Suitable for fluids, gases, waterjet cutting, high pressure test or food preservation and control system applications. Serves the automotive, aerospace, oil and gas industries.

Micro hydraulic power units: they generally have a maximum flow rate of 5 l/min (liters per minute) and a maximum pressure that can reach up to 250 bar. Micro hydraulic power units are compact units designed to be mounted on small motorized machines. They are generally equipped with direct current electric motors of 800 watts maximum.

The VECTOR MINI Pump is the latest addition to HYTORC’s line of advanced hydraulic power packs. Based on industry-leading VECTOR pump technology, this single-port high performance pump ...

The JETPRO 2-stage Hydraulic Power System is the most affordable lightweight pump on the market. The JETPRO’s compact design and one-gallon reservoir alleviates weight restrictions like ...

The modular small power unit ABPAC is based on a steel tank. The drive power reaches from 3 kW to 75 kW with a tank capacity of 100 to 630l. Further options like accumulator ...

Mini hydraulic unit driven by a single cylinder 4 stroke petrol engine. Cooling by forced air, starting with pull rope. 98cc, 2,2kW (3hp) at 3600t/min. Electronic ignition, starter pull ...

These power units are designed for use in locations where space is at a premium, or where the power of a NFPA/JIC-Style unit is needed in a smaller, less expensive package. ...

portable hydraulic Tools are driven by Hydraulic Power Units, and they are efficient, small, light and powerful. Doubtlessly, they provides convenient and dependable ...

The modular small power unit ABSKG is based on an aluminum tank. The drive power reaches from 0.37 kW to 7.5 kW with a tank capacity of 20 to 60l and an oscillating ...

The type HR120 mini hydraulic power pack features high pressure in the smallest space, with the option to use any installation position. The reversing function is activated by reversing ...

Mini hydraulic POWER PACKS are designed to operate single-acting and double-acting cylinders in simple high pressure hydraulic systems. The power units, ...

Hydraulic power units provide pressurized flow to hydraulic cylinders, motors, and other hydraulically-powered mechanisms. Hydraulic power units differ from regular pumps in that they regulate fluid temperature and have multiple stages. They are an integral part of machines that rely on hydraulic power for operation.

A hydraulic power unit is a pump that draws fluid from a reservoir and sends it to the motor. The fluid moves the components of the motor, which in turn rotates the shaft that supplies mechanical power. The fluid is then discharged into the reservoir, where it will work its way back into the pump and continue the cycle. In hydraulic cylinders, the hydraulic power unit pumps hydraulic fluid into the bottom chamber of the cylinder and pushes the piston rod up, which pushes the fluid in the other chamber back into the reservoir. The movement of this fluid pressurizes the chamber and extends the piston to its full length, giving the hydraulic cylinder its ability to push.

This mini power pack dimensions are very small and compact, so, we also call them small hydraulic power packs or small hydraulic power units. They offer high pressure with low flow for single action hydraulic systems or double acting small hydraulic cylinders.

Target Hydraulics provides small hydraulic power pack DC motors from 350 watts to 800 watts, and AC motors from 0.25Kw to 0.75Kw for 4 poles. All of the power packs are suited for house designs and manufacturer aluminum manifold blocks. Our aluminum manifold port threads are normally 1/4”BSPP or 3/8”BSPP.

Target Hydraulics designs and manufactures mini hydraulic power-packs. Our hydraulic power pack manufacturer is located in Ningbo, China. We produce high performance hydraulic power packs in China, and this enables Target Hydraulics to be competitive in the world market with reasonable prices.

Our Engineers design mini hydraulic power packs with  3D and 2D software for different applications. mini AC and DC power packs are our main products. Single and double acting power packs are popular ones.

Target Hydraulics small power pack hydraulic units are designed for different hydraulic system applications. Such as Construction Machinery/Agricultural Machinery/Wind Power/Mining etc

Target Hydraulics offers you a wide range of hydraulic products. small and mini power packs including single acting mini hydraulic pump 12v, hydraulic cylinder power packs, and AC or DC micro hydraulic power unit.

In this mini power pack, our well-proven radial piston pump from automotive engineering is integrated directly into the bell housing. As oil tank the unit has a round transparent tank with a M8x1 filler plug.

The type HR080 micro hydraulic power pack features high pressure in the smallest space, with the option to use any installation position. The reversing function is performed by reversing the direction of rotation of the motor. A directional valve is not needed. The motor is protected from overload by an integrated temperature switch. This hydraulic power pack is equipped with a DC or AC motor.

The type HR120 mini hydraulic power pack features high pressure in the smallest space, with the option to use any installation position. The reversing function is activated by reversing the motor’s direction of rotation. No directional valve is required. The motor is protected from overloads by a built-in temperature switch.

The mini hydraulic power unit type A is characterized by its modular design. In the power pack, an external gear pump is flanged to the equipment carrier and the oil reservoir is designed as a round plastic tank with an M 14x1.5 filler plug. The power unit is mainly used in automotive engineering, aviation, floor-lock systems as well as in decentralized hydraulic control systems.

Directional seated valves have zero leakage. Depending on the valve type, actuation is electromagnetic, pressure-actuated, mechanical or manual. The range includes seated valves and valve combinations. Directional spool valves are also a type of directional valve. They control the direction of movement and the velocity of single and double-acting hydraulic consumers. The range includes on/off directional spool valves, proportional directional spool valves and valve combinations.

The SLC1 chained valves are a combined design consisting of seated valves and dual check valves. They can be used to hold hydraulic actuators in position for long periods of time. Restrictor check valves are mounted on the cylinders for speed adjustment.

The TLC3 series connection add-on valve is a combined design consisting of a slide valve and a dual check valve. It can be used to hold hydraulic actuators in position for long periods of time. The built-in T-throttles also allow the user to pre-set the speed of the actuators.

International Fluid Power, Inc. is the leading authority in the upper Midwest region for compact hydraulic power units and systems. We offer a large range of hydraulic power units and custom hydraulic systems from a variety of manufacturers. We are able to meet your needs with a wide array of standard “off the shelf” power units as well as custom designed units to meet your specific requirements. Powered by AC or DC motors, air motors, gasoline, or diesel engines, we have the experience and know how to meet your needs. Special valve styles or mounting locations are not a problem. We build units for single use applications or higher volume OEM applications.

International Fluid Power, Inc. designs and builds custom hydraulic systems and circuits to meet the specific needs of our customers. Our extensive knowledge and experience coupled with many of the world’s premiere product lines, gives us the ability provide the highest quality hydraulic systems available in the market today. From design to installation, we will exceed your expectations.

Bucher Hydraulics is a leading and renowned manufacturer of hydraulic power units with a well established customer base throughout North America. Bucher Hydraulics manufacturers AC and DC hydraulic power units in Grand Rapids, MI for commercial and industrial applications. We offer a wide range of motors, reservoirs, valves, and integrated manifold valve circuits. In addition to our standard products, we are willing and able to manufacture power units to your exact specifications. Flow rates from .25 gpm to 15 gpm and pressures to 4000 psi.

Brevini Fluid Power S.p.A. product lines include AC and DC powered hydraulic power packs and systems. These power units are standardized compact units as well as customized hydraulic power packs to meet specific application requirements. Brevini Fluid Power power units offer uni-rotational, bi-rotational and miniature styles are available. Also included are Aron hydraulic valves including cartridge valves, solenoid valves, gear boxes and transmission components.

Brevini Fluid Power is a leading manufacturer of hydraulic components in Italy and Europe. Its headquarters is located in Reggio Emilia, Italy and has direct subsidiaries in Italy, France, England, The Netherlands, Germany, Romania, China, India, Singapore and the USA.

Morrell Group has been engineering, manufacturing, and supporting hydraulic power units of all types and sizes for over 40 years. We engineer and manufacture quality custom power units to support every application. We utilize a range of fixed and variable displacement pumps and an unparalleled choice of accessories and options to meet your needs. Morrell Group is an Engineering Partner, Systems Integrator, and Value-Added Distributor (ESV), which means we partner with your engineering team to get a complete grasp of how your system operates. First, we consider your application needs, timeline, and budget when engineering the ideal solution for your application. Then, we provide on-site support for best hydraulic power unit startup practices as well as lifetime troubleshooting support for our units. Browse each power unit"s pages below for more technical details and specifications, and get connected with our experienced team today.

Hydraulic Power Units are the main driving components of hydraulic systems. Consisting mainly of a motor, a reservoir and a hydraulic pump, these units can generate a tremendous amount of power to drive most any kind of hydraulic ram. Hydraulic Power Units are based on Pascal’s law of physics, drawing their power from ratios of area and pressure.

Hydraulic Power Units can generally be used in any application that requires heavy and systematic lifting or other requirements for the repeated use of powerful and directional force.

Consider all of the ways that hydraulic power units are used in things you see every day. Drive past any construction site and you’re likely to see some kind of heavy construction machine, be it a bull dozer, an excavator or even a skidsteer. All of these machines rely on hydraulic power units to do their work.

Fisherman rely on hydraulic power units to lift their nets and pots. Your auto mechanic uses a hydraulic power unit to lift your car high enough to walk around beneath it and make repairs. The Jaws of Life, a tool that has saved many lives in auto accidents, relies on a hydraulic power unit for its incredible cutting power. Farmers use hydraulic-driven machinery to tend and harvest their crops. The garbage truck that picks up your trash uses a hydraulic power unit to compact the garbage it collects. Your favorite amusement park ride probably utilizes hydraulics to lift you high and fast into the air and give you a soft, safe landing. Remember when you stepped on the brakes to avoid that last small animal that ran out into the road? Modern auto braking systems rely on the power of hydraulics.

It’s easy to overlook the widespread and impressive utility of hydraulic power units, but listing all of their applications it becomes clear that we rely on them for so much of what makes our society run smoothly and efficiently.

The experienced engineering team at Certified Power Solutions follows a proven quality, design and manufacturing process to develop hydraulic power units. Our high-quality mobile and industrial units range from 1 hp to 100 hp and beyond, and can be configured to utilize AC or DC current, or gas or diesel fuel. By using the best design practices and components from premier manufactures, we can supply the right hydraulic power unit for your application.

The CPS in-stock gas and diesel power units that can ship in 24–48 hours include: roll cages, engines, pump adapters, love-joy couplings, pumps, relief valves, reservoirs, return filters, pressure gauges, hoses, fittings and battery cages. Optional mounted oil coolers and directional control valves are available upon request. Custom power units are also available. Power units arrive assembled and ready to work upon arrival.

CPS has the capabilities to provide you the exact hydraulic power unit to get your job done. Some of the power unit applications that we have extensive experience with include: marine, in-plant, rock and gravel and industrial de-burring.

It"s only natural for a hydraulics company like Logan Industries to be good at manufacturing our own Hydraulic Power Units (HPUs).  Our engineers and designers are trained for this type of work and hold Fluid Power Certifications.  Our technicians have experience with building, assembling and testing our HPUs.  They are meticulous and take great pride in their manufacturing work.  Our customers have come to rely on our expertise and we are now first call for many of them.

We can manufacture any sort of power unit you might need.  We have designs for Electric powered, Diesel powered, Dual powered systems.  We have more designs for tandem pump strings, parallel pumps strings, and dual redundant pump strings.  We use only top quality parts for our filtering circuits, cooling circuits, open loop and closed loop circuits, directional control valves, pressure and flow valves, and everything else that goes into making an HPU a reliable piece of equipment to power your consumers.
