trw hydraulic pump supplier

TRW’s Aftermarket business has announced the publication of a 2015 catalogue to accompany its market leading hydraulic range. This news supports TRW’s position as a leading global supplier of OE quality safety critical braking parts.

Initially available in PDF format, it covers TRW’s seven hydraulic programmes: brake boosters; brake master cylinders; brake pressure valves; wheel cylinders; hoses (brake and clutch); clutch master cylinders and clutch slave cylinders (including concentric slave cylinders). It is divided into four sections: applications; buyers guide; images as seen in TecDoc and an OE cross reference section containing more than 11,000 parts.

Of particular note, the publication contains full details of TRW’s award winning programme of brake hoses which at the last count covered 240 million vehicles across Europe.

TRW’s Marcel Baemer, Marketing Data Manager Global Parts & Service explained: “As safety critical wear items operating under considerable stress, brake hoses should be regularly monitored to prevent system pressure dropping due to loss of brake fluid. With precise concentric fitting holes, our hoses ensure free flow of brake fluid; particularly important for cars fitted with modern Anti-Lock Braking Systems (ABS) and vehicle dynamic control systems, such as Electronic Stability Control (ESC) as it allows for optimum ABS or ESC pressure dump.”

White House Products Ltd. is proud to be a leading Ross hydraulics supplier. When you’re looking for Ross hydraulic motors, you can find them in our catalog, whether you need an orbital motor or hydraulic torqmotor. Officially known as TRW Ross, the brand is now part of Parker-Hannifin’s Hydraulic Pump/Motor Division.

Parker is known for a range of engineering products in hydraulics and other technologies, including pneumatics, process control, and fluid and gas handling, which are used in industrial, aerospace, and mobile equipment applications. The company was founded in 1917 and specializes in a wide range of motion and control technologies.

Ross motors and other products are produced at a 260,000-square-foot plant in Greenville, TN and in Germany. The Greenville facility was purchased by Parker in 1993, it had originally opened in 1972 as part of the TRW Ross Gear Division. A range of low-speed, high-torque motors and hydrostatic steering components are manufactured there.

Typically featuring an internal trochoidal gear design, a high-torque hydraulic orbital motor effectively converts hydraulic fluid power into mechanical rotary motion in a system. A distributor valve directs the fluid as it moves through the chamber. Orbital motors are designed to generate high rotational torque which is directly proportional to the pressure exerted by the load and the motor displacement.

We stock commonly used Parker supersessions of Ross hydraulics components and will even help match parts with your application. Customers trust our repair service as well. If there’s a replacement motor you are looking for, browse our inventory and log in to make your purchase or view pricing, or call +44 (0) 1475 742500 for more information.

Direct drop in replacement for TRW Ross hydraulic motors. Our motors meet or exceed all specifications for RPM, flow rate, pressure and torque for the Ross hydraulic motors.

Drop in equivalent to Ross MAB24009 hydraulic motor. Low speed, high torque. 18.08 cubic inch displacement. Wheel mount. 1" shaft with key. 7/8"-14 SAE ports. 250 RPM maximum speed. 7169 inch lbs. of torque. 19.81 GPM maximum flow rate. 2973 PSI...

Drop in equivalent to Ross MAB24004 low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM continuous...

Drop in equivalent to Ross MAB24002 hydraulic motor. Low speed, high torque. 18.08 cubic inch displacement. 6 bolt magneto flange mount. SAE 6B spline shaft. 7/8"-14 SAE ports. 250 RPM maximum speed. 7169 inch lbs. of torque. 19.81 GPM maximum flow...

Drop in replacement for Ross MAB16004 low speed, high torque hydraulic motor. 12.20 cu. in. / rev displacement. Maximum pressure 2061 PSI continuous. Torque 3540 in-lb. continuous. Maximum speed 375 RPM continuous...

Drop in equivalent to Ross MAB40008 hydraulic motor. Low speed, high torque. 28.18 cubic inch displacement. 6 bolt magneto flange mount. 1" shaft with woodruff key. 7/8"-14 SAE ports. 160 RPM maximum speed. 9602 inch lbs. of torque. 19.81 GPM...

Drop in equivalent to Ross MAB24110 hydraulic motor. Low speed, high torque. 18.08 cubic inch displacement. 6 bolt magneto flange mount. SAE 6B spline shaft. 7/8"-14 SAE ports. 250 RPM maximum speed. 7169 inch lbs. of torque. 19.81 GPM maximum flow...

Drop in equivalent to Ross MAB24022 hydraulic motor. Low speed, high torque. 18.08 cubic inch displacement. 6 bolt magneto flange mount. SAE 6B spline shaft. 7/8"-14 SAE ports. 250 RPM maximum speed. 7169 inch lbs. of torque. 19.81 GPM maximum flow...

Drop in equivalent to Ross MAB16110 low speed, high torque hydraulic motor. 12.20 cu. in. / rev displacement. Maximum pressure 2061 PSI continuous. Torque 3540 in-lb. continuous. Maximum speed 375 RPM continuous...

Drop in equivalent to Ross MAB16056 low speed, high torque hydraulic motor. 12.20 cu. in. / rev displacement. Maximum pressure 2061 PSI continuous. Torque 3540 in-lb. continuous. Maximum speed 375 RPM continuous...

Drop in equivalent to Ross MAB16016 hydraulic motor. Low speed, high torque. 11.96 cubic inch displacement. 6 bolt magneto flange mount. 1-1/4" 14 spline shaft. 7/8"-14 SAE ports. 330 RPM maximum speed. 4691 inch lbs. of torque. 17.96 GPM maximum...

Drop in equivalent to Ross MB180603CCCB low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM continuous...

Drop in equivalent to Ross MB180603CCCA low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM continuous...

Flint Hydraulics, Inc. is an authorized stocking distributor and Rapid Delivery Center for the Danfoss Power Solutions series of low speed high torque hydraulic motors. From the diminutive OML to the robust OMV series, the … Read more

Parker is a global manufacturer of hydraulic pumps, transmissions, gear pumps and motors, engineering superior products for a wide variety of applications. Delivering unsurpassed quality and performance, Parker’s extensive line of hydraulic pumps and motors helps you select the right product for your hydraulic application. Achieve easier, safer, and more efficient operation. The Pump & Motor Division assures consistent quality, technical innovation, and premier customer service.

Stocking distributor & global shipper of NOP oil pumps such as trochoid pumps used on all types of Japanese machinery & equipment for industrial & machinery lubrication & machine tools. High pressure coolant pumps for metalworking. Lubrication systems for circulation oil & direct lubrication for bearings & headstock & transmissions, trochoid pumps are available with capacities ranging from 1 L/min up to 586 L/min with pressure ranging from 0.5MPa up to4 MPa. Trochoid pumps are also available with or without integrated motor. Markets served include original equipment manufacturer (OEM), machine tool builders, distributors, wholesalers & service companies.
