viton mechanical seal free sample

M7N mechanical seal made by lepu seal is a popular seal replacement for eagleburgmann m7n. this seal we made is a Self cleaning effect seal, and insensitive to low solids contents, this seal design offer strong flexibility in torque transmissions, and for this seal, Lepu seal offer many kinds of selection material for the seal face.

Mechancial seal m7n is widely used in many industry pumps, especially for Low solids content media, Chemical standard pumps, Shipbuilding, Gear wheel feed pumps. If in high chemical condition, PTFE is recommend for secondary seals , as ptfe offer high chemical resistance.

Guangzhou Lepu machinery CO., LTD becomes one of the leading mechanical seal supplier in south of china, we focus in designing and manufacturing mechanical seal for many kinds of famous brand pumps, our mechanical seal cover many kinds of industry like food, petrol chemical, paper making, sea ship, and so on.

A dry gas seal is a revolutionary way of sealing machines and protecting them from dust, moisture and other contaminants. A dry gas seal is a sealing device that uses pressurized gas to keep two surfaces from touching. The most common type of dry gas seal is the O-ring, which is used in many applications, including mechanical seals, piston rings, and gaskets. Dry gas seals are also used in many other industries, such as the food and beverage industry, where they are used to seal containers and prevent contamination. This type of seal not only helps to keep the machine running with maximum efficiency but also significantly reduce downtime, making it cost-effective in the long run. In this article, we"ll explore what a dry gas seal is, how it works and why you should consider using it for your machinery. By understanding the benefits of a dry gas seal and its uses, you can make an informed decision about the best sealing system for your needs. How does a dry gas seal work?Dry gas seals work by using a series of labyrinths to separate the high pressure seal gas from the atmosphere. The labyrinths are formed by a series of grooves and ridges on the surface of the seal ring. The seal ring is rotated at high speed, causing the gas to flow through the labyrinths. The gas is then forced through an aperture in the center of the seal ring, where it escapes into the atmosphere. What is a dry gas seal used for?Dry gas seals are used on rotating equipment to help minimize the leakage of high pressure gases from the inside of the machinery. This helps to reduce maintenance costs and improve safety. Dry gas seals are commonly used in applications such as pumps, compressors, turbines, and blowers. Advantages of a dry gas sealThere are many advantages of a dry gas mechanical seal. One advantage is that they are much simpler in design than other types of seals, making them more reliable and easier to maintain. Additionally, dry gas seals do not require the use of any lubricating fluids, which can leak or evaporate over time. This makes them more environmentally friendly and cost-effective in the long run. Finally, dry gas seals have a much longer lifespan than other types of seals, meaning that they need to be replaced less often.Disadvantages of a dry gas sealThere are several disadvantages of dry gas seals, including: - they can be expensive to purchase and install- they require careful maintenance and regular inspection- they can be susceptible to wear and tear- they can leak if not maintained properlyHow to choose the right dry gas seal for your applicationThere are a few key factors to consider when choosing the right dry gas mechanical seal for your application. The most important factor is the type of fluid being sealed. Gas seals are designed to seal either liquids or gases, but not both. Make sure to choose a gas seal that is compatible with the fluid you are sealing.Another important factor to consider is the pressure of the fluid being sealed. Gas seals are rated for different maximum pressures, so make sure to choose one that can handle the pressure of your application.Finally, take into account the size and shape of the sealing surfaces. Gas seals come in a variety of sizes and shapes to fit different applications, so make sure to choose one that will fit your needs.ConclusionDry gas seals are an extremely important component for many industrial operations, and their ability to prevent leaks has made them invaluable in a variety of applications. Understanding the basics of how dry gas mechanical seal work and how they can be used effectively is helpful when considering the various options available for any specific application. With the right choice, dry gas seals can provide reliable, leak-free performance which will save time, money and resources while ensuring safety and reliability. Lepu dry gas seal manufacturer provides best quality flowserve dry gas seal and dry gas seal. Welcome to contact us!

No carbon dust contamination, eliminates process contamination from mechanical seal face wear. True dry-running design, balanced double cartridge seal, can be run with a barrier fluid.

Whether to use Buna or Viton elastomers — often referred to as O-rings, seals, or gaskets — isn’t always an easy choice. These types of elastomers are synthetic rubber parts in a pump that help prevent leakage and are critical to the durability and long-term success of a pump system.

Knowing which sealing option is right for your pump requires identifying your specific application and intended use. Let’s break down the difference between Buna and Viton elastomer materials and the role each plays in your pump’s performance.

Buna seals are standard in most pumps and work well for most cleaning and fluid pressurizing applications. This form of synthetic rubber is generally chemical-resistant, standing up to oil, fuel, and other harsh compounds.

Common commercial applications where Buna seals are used include carpet extractors, pressure washers, marine dock sprayers, misters, and hydrostatic testing.

Viton is a brand of synthetic rubber and fluoropolymer elastomer commonly used in O-rings and other molded extruded goods. Viton is a registered trademark of DuPont and is sometimes generically referred to as FKM.

Viton seals also feature some chemical resistance and are ideal in pumps used for agricultural, pest control, disinfection, mold remediation, and lawn care sprayers because of its resistance to hydrocarbons found in some of the compounds used. Another reason these types of applications may be more suited to Viton O-rings is because of their ability to stand up to sun exposure and other environmental conditions.

So, is Buna better than Viton? Assuming chemical compatibility is not a factor, we generally consider Buna O-rings to be better performers because of their resistance to a characteristic known as “compression set.”

When you compress a Viton seal, it can conform to the shape it is compressed into even after it’s removed. This isn’t desirable since the job of an elastomer is to press outward onto the surface it is supposed to seal against. When you compress Buna, on the other hand, it rebounds back to its original shape once it’s removed.

While certainly not exaggerated to the extent of the cookie dough example, Viton O-rings tend to conform slightly to the shape they’re compressed into, whereas the Buna O-ring springs back to its original shape and provides a more reliable seal.

Ultimately, you need to determine the chemicals you’ll be using. Even though Viton elastomers are often used with disinfection sprayers that use harsh chemicals, for example, that doesn’t mean Buna seals are out of the question. If you use sodium carbonate — a commonly used disinfection compound — it is compatible with both types of O-rings, so we’d recommend using Buna. Sodium Hypochlorite (household bleach), on the other hand, can degrade Buna seals, making Viton the better choice.

Pumptec provides both Buna and Viton as standard options for our pumps, along with other elastomer types for unique applications. It all comes down to your use, performance needs, and the fluids being pumped through your system. It’s best to speak with one of our pump experts to ensure you’re choosing the right kind. We’re always happy to help.

Since failure of the mechanical seal on the shaft is the number one cause of pump shutting down, it is important to know the standard terms of the world of mechanical seals.

Mechanical seals are comparable to precision instruments. These seals use margins with many decimal places. The mechanical seal life depends on many factors, and it can vary from a few intense minutes to many trouble-free years. In general it can be stated that: the more attention paid to the mechanical seal and related equipment, the longer they will last.

Years ago, packing materials such as stuffing box packing were used for most shaft seals. These types of shaft seals required a fair amount of leakage to keep the packing properly lubricated and cooled. Until 1915 the mechanical seal was invented. This shaft seal managed to keep the fluid in by using two incredibly flat surfaces (one that rotates with the shaft, and one stationary in the housing). Despite the fact that these treads also need a little bit of ‘leakage’ to create a hydrodynamic layer, this is often not noticeable as this liquid evaporates. Most pumps today have mechanical seals. However, because the parts and surfaces are so delicate, it is also the number one cause of pump failure. This requires a better understanding of this type of seal and its application.

A set of (very flat lapped) treads as primary seal: the minimum distance between these treads, which are perpendicular to the shaft, minimizes the leakage. Often two different materials are used as the tread, a harder and a softer material, to prevent the materials from sticking together. One of the treads is often anti-friction corrosion material such as carbon graphite. A relatively hard material such as silicon carbide (SiC) or ceramic alumina is often used for the other tread. However, when processing abrasive substances, two hard surfaces are normally used.A tread is mounted stationary in a house.

Mechanical seals require a fluid to maintain lubrication. The running surfaces are usually lubricated by a very thin layer of liquid (or gas) between the two running surfaces. Lubrication can also come from another fluid other than the product, depending on the seal requirements.

Pusher seals use a secondary seal that moves axially along the shaft or shaft sleeve to maintain pressure on the running surfaces. This allows the seal to compensate for wear and any less accurate shaft alignment. The advantage is that this seal type is the cheapest. The main disadvantage of this configuration is that the secondary seal can gall on the shaft or shaft sleeve, especially when processing abrasive product.

This is the category in which the bellow seals fall. These seals do not use a secondary seal that must be able to move along the shaft or shaft sleeve to maintain contact. The secondary seals do not move with this type of seal under any circumstances, not even during use. The tread wear is compensated for by an elastomer or metal bellows. A disadvantage of this type of seal is the higher cost price of the seal and that a larger seal must be used in a corrosive environment because the material of the bellows is otherwise too thin.

We speak of a balanced seal if the pressure on the running surfaces caused by the pressure in the system is taken into account. It may sound crazy if the goal is to achieve shaft seal, but a mechanical seal must leak! After all, the running surfaces of the primary seal must be lubricated with the pumped product. When the pressure on the product side exceeds approximately 250 psid, the pressure on the treads can increase to such an extent that no liquid film can form between the surfaces. The lack of lubricating film will cause the seals to wear out very quickly.

To overcome this problem, the balanced seal was introduced in 1938. With a balanced mechanical seal, high pressure is taken into account by adjusting the surface of the tread, which distributes the stuffing box pressure over a larger surface. Balanced seals are easy to recognize, there is a step in the shaft sleeve and/or the running surface. Incidentally, this works a bit more complicated with a metal bellow, but the principle remains the same. Mechanical seals can also be designed to balance for overpressure on both sides of the tread assembly.

Cartridge seals consist of a pre-mounted mechanical seal on a shaft sleeve that can be installed as a whole over the shaft or shaft sleeve. Cartridge seals are very easy to install and the chance of short service life due to suboptimal installation is less probable. It should come as no surprise that cartridge seals are a lot more expensive than the previously discussed seals. On the other hand, there are lower maintenance costs. Incidentally, it is not always possible to apply a cartridge seal if, for example, there is no space in the house.
